WL-V420 Vertical Automatic Packaging Machine FOR CHIPS

FOB Reference Price:Get Latest Price
$10,000.00 - $12,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Engineers available to service machinery overseas
Application:
Food, Other
Packaging Material:
Plastic
Type:
Other
Condition:
New
Packaging Type:
Bags, Pouch, Stand-up Pouch
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V
Place of Origin:
Guangdong, China
Model Number:
WL-V420
Weight:
500kg
Certification:
CE Certificate
Packaging & Delivery
Port
Zhongshan
Lead Time :
Shipped in 30 days after payment
Product Description

product name:WL-V420 Vertical Automatic Packaging Machine FOR CHIPS


keyword:Automatic scale, Packaging machine, Packaging project


I. Main performance and structural feature:

*Imported PLC computer control system with human-machine interface and visual touch screen.

*Precise position with servo film transporting system, excellent complete machine performance and nice packing;

* Minimize the loss with perfect automatic alarm protection function;

* Temperature independent control system ,precision get to±1℃.

* Horizontal , vertical temperature control ,suitable for various of mix film , PE film,packing material, etc.

*Packing type diversification , pillow sealing, standing type ,bags-connected punching etc.

* Bag-making , sealing, packing, print date in one operation.



II. Application:

* It’s suitable to use in automatic packaging solid material, such as puffy food, shrimp roll, peanut, popcorn, cornmeal, seed, sugar and salt etc. which shape is roll, slice and granule.



Ⅲ. Optional machines:

The machine can be matched with multihead weigher, can measuring machine, manual bucket conveyor and auger filler machine.

SPECIFICATIONS FOR WL-V420 Vertical Automatic Packaging Machine
Mode
WL-V420
Packaging speed
5-60 PPM
Pouch size
(L)50-300mm (W)60-200mm
Pouch making mode
Pillow-type pouch, standing pouch, punch device
Range of measuring
150-1300ml
Max width of packaging film
420mm
Air consumption
0.65mpa
Total power/voltage
2.2KW/220V 50-60Hz
Dimension
1080(L)*1300(W)*1400(H)mm
Machine weight
500kg
Certifications
Detailed Images
Our Service
Packing & Delivery
Packaging
Size
Weight



Packaging Details
This crate box is specially for export. It is not only reuseable but also free from fumigation.
