Stainless Steal High detecting sensitivity 14 head multihead weigher

FOB Reference Price:Get Latest Price
$100.00 - $10,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
M14
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Engineers available to service machinery overseas
Application:
Food
Packaging Material:
Plastic
Type:
Other, Other
Condition:
New
Packaging Type:
Cartons
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V
Power:
3.5kw
Place of Origin:
Guangdong, China
Brand Name:
WELIN
Weight:
500kg
Dimension(L*W*H):
980*680*1150
Certification:
CE
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
Free Fumigation Plywooden Case for exporting, it's quick-connect design for easy open and re-usable;
Inner plastic film wrapping protect the goods from salting, wind or damage
Port
ZHONGSHAN
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated
Video Description
Product Description

♦ OVERVIEW

Welin's new modular multiple head combination weighing filler series are with the feature of hi-speed, hi-accuracy and reliable performance. Adopting numbers combination theory, CPU auto calculate and choose the closest target weight combination hoppers to dump to the downstream units, such as manual filling, various packing machine, or tray, bottle, bucket, can filling device, also integrated with weight checker, metal detector or X-ray. Widely applied for food or non-food packing industry, such as rice, seeds, nuts, candy, snack food, potato chips, IQF food, biscuits, bread, fresh vegetable and fruits, hardware or plastic parts, etc. Besides, as for fragile, hard-flowing, long-stick or mixed products, basing on years successful experience, we can custom mechanical and program to meet the project requirements, such as dimple plate, timing hopper, inclined feeder pan, piece counting, 1 to 2-3-4-5 points dump or IP65 waterproof design, etc.

♦ Multihead weighers working principles

Products to be firstly delivered by conveyor and fed into the upper bunker funnel.
Then it can be dispersed to linear Feeder Pans from the vibrating Top Cone.
The products feeding thickness can be changed by adjusting the height of the Infeed Funnel.
Products are distributed evenly into each Linear Feeder Pan, stored in Feed Bucket.
When Weigh Buckets complete the previous weighing and after they are dropped out,
products to be weighed in Feed Buckets can be fed into Weigh Buckets to prepare for next
combination. Meanwhile this multihead weighers can work with other equipments like
packaging machines or conveyor by signal communication

♦ Multihead weighers main parts

1 Indeed Funnel/Supply hopper                2 Level Sensor                        3 Top Cone 4 Linear Feeder Pan

5 Feed Bucket/Hopper                                6 Weigh Bucket/Hopper        7 discharge/dump/Collating Chute

8 Machine body or Base Frame                9 Collating Funnel                  10 Wire For Control Panel

11 Main Power switch                               12 Display                                  13 Hook for display

14 Hang Bolt                                                 15 Aluminum Case                  16 Collecting hopper/bucket

♦ APPLICATION

This unit is with special design on the feeder, hopper and dump chute, which is ideal for hardware and plastic weighing filling, etc.

♦ Leading Features

Equiped high level hopper protection hopper and chute for hardware impacting.
Adopt high precision load cell for reliable performance.
Program recovery function can reduce improper-operation.
Auto pause when no enough products ensure running fluency;
Preset 100 programs and help menu for easy operation;
Linear amplitude can be adjusted independently;
Product can be max. 30mm length;
Full 304SUS material building for food industry;
Free tool parts released design for easy clean;

♦ SPECIFICATIONS

Model
WL-M14
Heads No.
14
Weighing Range
20-2000g
Accuracy
±0.2-1.5g
Running Speed
120 weightments/min
Hopper Capacity
1600ml with protection inside
Control Panel
10.4'' User's friendly Touch Screen
Load Cell Capacity
10kg strain gauge load cell
Driving System
Step Motor
Material feeding
By conveyor
Control System
Modular MCU Control
Building Material
304SUS
Option
Feeding conveyor, Timing/Collecting Hopper, Dimple Plate
Power Requirement
AC200-240V+10%-15%, 1Phase, 50/60HZ, 520VA
Products View
Company Information

Established in 2011, WEIGHLIN dedicated in food weighing packaging machines, included high speed high precision multihead weighers, economical practical linear weighers, dynamic weight checking and grading, performed pouches packing machine, high quality accessories such as platform and conveyors, also full feeding weighing packaging inspecting line, etc and other related customized packaging machines. Quality packaging solution is from Weighlin years of focus and understanding of the packaging industry. WEIGHLIN strives for perfection in the pursuit of quality, while taking into account easy to operate, easy to disassemble, easy to clean, small investment, stable performance, so that the packaging carry, deliver and create value.
